Various lysates were subjected to SDS PAGE followed by western blot with 80170-1-RR (PDI antibody) at dilution of 1:10000 incubated at room temperature for 1.5 hours. This data was developed using the same antibody clone with 80170-1-PBS in a different storage buffer formulation.

WB result of PDI antibody (80170-1-RR; 1:6000; incubated at room temperature for 1.5 hours) with sh-Control and sh-PDI transfected HEK-293 cells. This data was developed using the same antibody clone with 80170-1-PBS in a different storage buffer formulation.

Immunohistochemical analysis of paraffin-embedded human prostate cancer tissue slide using 80170-1-RR (PDI antibody) at dilution of 1:1000 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0). This data was developed using the same antibody clone with 80170-1-PBS in a different storage buffer formulation.

Immunohistochemical analysis of paraffin-embedded human normal colon slide using 80170-1-RR (PDI antibody) at dilution of 1:2000 (under 20x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0). This data was developed using the same antibody clone with 80170-1-PBS in a different storage buffer formulation.

Immunohistochemical analysis of paraffin-embedded human prostate cancer tissue slide using 80170-1-RR (PDI antibody) at dilution of 1:1000 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0). This data was developed using the same antibody clone with 80170-1-PBS in a different storage buffer formulation.

Biolayer interferometry (BLl) kinetic assays of 80170-1-RR against Human PDI were performed. The affinity constant is 13.8 nM.
