TGOLN2,TGN46 Recombinant antibody

TGOLN2,TGN46 Recombinant Antibody for WB, IHC, IF/ICC, FC (Intra), IP, ELISA

Host / Isotype

Rabbit / IgG

Reactivity

human

Applications

WB, IHC, IF/ICC, FC (Intra), IP, ELISA

Conjugate

Unconjugated

CloneNo.

230376D6

Cat no : 83099-2-RR

Synonyms

TGOLN2, TGN38 homolog, TGN38, hTGN51, hTGN48

Validation Data Gallery

Filter:
  • Western Blot (WB) analysis of various lysates using TGOLN2,TGN46 Recombinant antibody (83099-2-RR)

    WB analysis using 83099-2-RR

    Various lysates were subjected to SDS PAGE followed by western blot with 83099-2-RR (TGOLN2,TGN46 antibody) at dilution of 1:10000 incubated at room temperature for 1.5 hours.

  • Immunoprecipitation (IP) experiment of HeLa cells using TGOLN2,TGN46 Recombinant antibody (83099-2-RR)

    IP experiment of HeLa using 83099-2-RR

    IP result of anti-TGOLN2,TGN46 (IP:83099-2-RR, 4ug; Detection:83099-2-RR 1:2000) with HeLa cells lysate 980 ug.

  • Immunohistochemistry (IHC) staining of human stomach cancer tissue using TGOLN2,TGN46 Recombinant antibody (83099-2-RR)

    IHC staining of human stomach cancer using 83099-2-RR

    Immunohistochemical analysis of paraffin-embedded stomach cancer slide using 83099-2-RR (TGOLN2,TGN46 antibody) at dilution of 1:2000 (under 20x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

  • Immunofluorescence (IF) / fluorescent staining of HeLa cells using TGOLN2,TGN46 Recombinant antibody (83099-2-RR)

    IF Staining of HeLa using 83099-2-RR

    Immunofluorescent analysis of (4% PFA) fixed HeLa cells using TGOLN2,TGN46 antibody (83099-2-RR, Clone: 230376D6 ) at dilution of 1:250 and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L) (SA00013-2).

  • Immunofluorescence (IF) / fluorescent staining of HeLa cells using TGOLN2,TGN46 Recombinant antibody (83099-2-RR)

    IF Staining of HeLa using 83099-2-RR

    Immunofluorescent analysis of (4% PFA) fixed HeLa cells using TGOLN2,TGN46 antibody (83099-2-RR, Clone: 230376D6 ) at dilution of 1:250 and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L) (SA00013-2), CL594-Phalloidin (red).

  • Flow cytometry (FC) experiment of HepG2 cells using TGOLN2,TGN46 Recombinant antibody (83099-2-RR)

    FC experiment of HepG2 using 83099-2-RR

    1x10^6 HepG2 cells were intracellularly stained with 0.4 ug TGOLN2,TGN46 Recombinant antibody (83099-2-RR, Clone:230376D6) and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L) (SA00013-2)(red), or 0.4 ug Isotype Control (blue). Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C).

  • Affinity and Kinetic Characterization of 83099-2-RR

    Affinity and Kinetic Characterization of 83099-2-RR

    Biolayer interferometry (BLl) kinetic assays of 83099-2-RR against Human TGOLN2,TGN46 were performed. The affinity constant is 0.633 nM.

☆大好評トライアルサイズ ¥20,000～！ >>> 一次抗体特別価格キャンペーン開催中！

Tested Applications

Positive WB detected inA549 cells, HeLa cells, PC-3 cells, PC-12 cells, human kidney tissue
Positive IP detected inHeLa cells
Positive IHC detected inhuman stomach cancer tissue
Note: suggested antigen retrieval with TE buffer pH 9.0; (*) Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0
Positive IF/ICC detected inHeLa cells
Positive FC (Intra) detected inHepG2 cells

Recommended dilution

ApplicationDilution
Western Blot (WB)WB : 1:5000-1:50000
Immunoprecipitation (IP)IP : 0.5-4.0 ug for 1.0-3.0 mg of total protein lysate
Immunohistochemistry (IHC)IHC : 1:1000-1:4000
Immunofluorescence (IF)/ICCIF/ICC : 1:125-1:500
Flow Cytometry (FC) (INTRA)FC (INTRA) : 0.40 ug per 10^6 cells in a 100 µl suspension
It is recommended that this reagent should be titrated in each testing system to obtain optimal results.
Sample-dependent, Check data in validation data gallery.

Product Information

83099-2-RR targets TGOLN2,TGN46 in WB, IHC, IF/ICC, FC (Intra), IP, ELISA applications and shows reactivity with human samples.

Tested Reactivity human
Host / Isotype Rabbit / IgG
Class Recombinant
Type Antibody
Immunogen TGOLN2,TGN46 fusion protein Ag4470 相同性解析による交差性が予測される生物種
Full Name trans-golgi network protein 2
Calculated molecular weight 447 aa, 47 kDa
Observed molecular weight 90-100 kDa
GenBank accession numberBC028219
Gene symbol TGN46
Gene ID (NCBI) 10618
Conjugate Unconjugated
Form Liquid
Purification MethodProtein A purification
Storage Buffer PBS with 0.02% sodium azide and 50% glycerol pH 7.3.
Storage ConditionsStore at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20oC storage.

Background Information

TGN46 (TGOLN2), the human homologue of rat Tgn38, is a transmembrane glycoprotein predominantly localized to the TGN (trans-Golgi network). TGN is a major secretory pathway sorting station for proteins and lipids. TGN46 may be involved in regulating membrane traffic to and from TGN. Alternatively spliced transcript variants encode different TGN46 isoforms. TGN46 has an apparent molecular mass of 100-150 kDa, suggesting extensive O- and N-glycosylations.

Protocols

Product Specific Protocols
WB protocol for TGOLN2,TGN46 antibody 83099-2-RRDownload protocol
IHC protocol for TGOLN2,TGN46 antibody 83099-2-RRDownload protocol
IF protocol for TGOLN2,TGN46 antibody 83099-2-RRDownload protocol
IP protocol for TGOLN2,TGN46 antibody 83099-2-RRDownload protocol
Standard Protocols
Click here to view our Standard Protocols
