CoraLite® Plus 488-conjugated ATPB Monoclonal antibody

ATPB Monoclonal Antibody for IF/ICC

Host / Isotype

Mouse / IgG2b

Reactivity

Human, Mouse , Rat

Applications

IF/ICC

Conjugate

CoraLite® Plus 488 Fluorescent Dye

CloneNo.

1A11B9

Cat no : CL488-66600

Synonyms

ATP5B, ATPB, ATPMB, ATPSB, Cell and organelle markers, Mitochondria Marker, Mitochondrion Marker

Validation Data Gallery

Filter:
  • Immunofluorescence (IF) / fluorescent staining of HepG2 cells using CoraLite® Plus 488-conjugated ATPB Monoclonal anti (CL488-66600)

    IF Staining of HepG2 using CL488-66600

    Immunofluorescent analysis of (4% PFA) fixed HepG2 cells using CoraLite® Plus 488 ATPB antibody (CL488-66600, Clone: 1A11B9 ) at dilution of 1:200, CL594-Phalloidin (red).

☆大好評トライアルサイズ ¥20,000～！ >>> 一次抗体特別価格キャンペーン開催中！

Tested Applications

Positive IF/ICC detected inHepG2 cells

Recommended dilution

ApplicationDilution
Immunofluorescence (IF)/ICCIF/ICC : 1:50-1:500
It is recommended that this reagent should be titrated in each testing system to obtain optimal results.
Sample-dependent, Check data in validation data gallery.

Product Information

CL488-66600 targets ATPB in IF/ICC applications and shows reactivity with Human, Mouse , Rat samples.

Tested Reactivity Human, Mouse , Rat
Host / Isotype Mouse / IgG2b
Class Monoclonal
Type Antibody
Immunogen ATPB fusion protein Ag11177 相同性解析による交差性が予測される生物種
Full Name ATP synthase, H+ transporting, mitochondrial F1 complex, beta polypeptide
Calculated molecular weight 529 aa, 57 kDa
Observed molecular weight45-57 kDa
GenBank accession numberBC016512
Gene symbol ATPB
Gene ID (NCBI) 506
Conjugate CoraLite® Plus 488 Fluorescent Dye
Excitation/Emission maxima wavelengths493 nm / 522 nm
Form Liquid
Purification MethodProtein A purification
Storage Buffer PBS with 50% Glycerol, 0.05% Proclin300, 0.5% BSA, pH 7.3.
Storage ConditionsStore at -20°C. Avoid exposure to light. Stable for one year after shipment. Aliquoting is unnecessary for -20oC storage.

Background Information

ATP5B, also named as ATPMB and ATPSB, belongs to the ATPase alpha/beta chains family. It is a high affinity HDL receptor for apolipoprotein A1. ATP5B is a subunit of mitochondrial ATP synthase (F1F0 ATP synthase or Complex V ). ATP5B has a calculated molecular mass of 57 kDa and ~5 kDa transit peptide can be removed in the mature form.

Protocols

Product Specific Protocols
IF protocol for CL Plus 488 ATPB antibody CL488-66600Download protocol
Standard Protocols
Click here to view our Standard Protocols
